Classic CUT 60 Three Phase Welding Machine
SKU: ST-TCWM-134
Delivery By: Jul 2 - Jul 4
MRP : ₹35670 ₹28000
22% OFF!
Delivery By: Jul 2 - Jul 4 Easy Return
& Refund
& Refund
Quality
Assurance
Assurance
Trusted
Delivery
Delivery
After Sales
Assistance
Assistance
Buyer
Protection
Protection
₹28000 (Including GST)
MRP : ₹35670
22% OFF!
Get Extra ₹420 OFF on Prepaid Orders
QTY :
Short Description
Input Voltage (V) : AC380V ± 10%
Rated Input Current (A) : 12
No-load Voltage (V) : 240
Output Current Range (A) : 20-70
Specifications
Description
Classic CUT 60 Three Phase Welding Machine
Specification:
- Model No : CUT 60
- Product Type : Welding Machine
- Brand : Imported
- Phase : Three Phase
- Input Voltage (V) : AC380V ± 10%
- Frequency (HZ) : 50
- Rated Input Current (A) : 12
- No-load Voltage (V) : 240
- Output Current Range (A) : 20-70
- Rated Output Voltage (V) : 140
- Duty Cycle (%) : 60
- Input Power Capacity (KVA) : 9.5
- Arc Ignition : Contact
- Efficiency (%) : 85
- Power Factor : 0.93
- Insulation Grade : F
- Housing Protection Grade : IP21S
- Air Pressure (KG) : 4-5
- Cutting Thickness (mm) : 10-14
- Dimension (inch) : 20 x 8 x 15
- Net Weight (kg) : 19 (Approx)
Note :
- Do not use the welder for work other than welding.
- Do not touch the live part.
- Do not solder in places where skimming, cleaning and spraying are required.
- When using, please wear a protective cover or protective clothing.
